Junckers Unobat 78+ System

This is a permanent wood system, perfect for all types and sizes of sport, health, fitness and dance facilitiesThis is a permanent wood system, perfect for all types and sizes of sport, health, fitness and dance facilities.

The Unobat 78+ Wood Sport Floor System by Junckers set the new standard for athlete comfort, safety and adaptability. The next evolution in sport flooring, a sub-construction batten system is engineered to deliver superior impact reduction and consistent ball bounce. A shock-absorbing pad on the wedges minimize separation during installation to create an exceptional sport experience. Easy, precise installation is assisted by integrated sleepers and single component wedges with shock pads, adjusting height as needed for even or uneven subfloors.

Junckers Unobat 78+ System

Details/Features

  • Permanent wood sport floor system
  • Single layer batten construction
  • Pre-attached wedges/shock-absorbing pads
  • Polythene moisture barrier
  • Factory-finished sport finish for ready-play
  • Minimal maintenance
  • Long-lasting value
  • Consistent ball bounce
  • Balanced grip & surface friction
  • Elevated shock absorption & stability
  • Sport skirting available

Specifications

  • 5” wide floorboards
  • 12’ long prefinished sealed planks
  • 7/8” thick (22mm) surface
  • Double dovetail joints
  • Install: over even/uneven subfloor
  • Radiant heating compatible
  • Batten Centers; 13 ¼” (336mm)  / 16 3/16” (411mm)
  • 3 1/16” (78mm) to 8 1/16” (205mm) total thickness
  • Sand and Re-seal

COLORS: Ask about custom colors
